Product family

NET wireless Mesh

The NET sensors use Bluetooth Mesh (SIG) to Wirepas or other wireless technologies for reliable, flexible control of DALI luminaires.

The sensors in the NET product family connect wirelessly via mesh networks from third-party providers such as Bluetooth or Wirepas, can be conveniently configured via an app and control lighting systems via the DALI bus. They are compatible with various ecosystems such as Silvair, Casambi and Ingy and fully support their functions and settings.


Your benefits at a glance
✓ Proven PIR or HF presence sensors with constant light control
✓ DALI interface/control
✓ Products for offices, staircases, car parks
✓ Available for various mesh network systems

Product overview

sensotec-sensor-pir.svg
PIR NET sensor

The unobtrusive PIR presence detector with a detection area of 4x4m (movement 6x6m) is a compact and reliable recessed luminaire sensor for applications up to a maximum height of 5m.

sensotec-sensor-hf2.svg
HF2 NET sensor

The HF sensor module has a detection range of up to 8m at a maximum height of 3.5m. The presence detection is carried out through glass and non-metallic materials and can therefore be used inside luminaires.

sensotec-extension-net.svg
Extension NET

The extension is used to expand the Bluetooth mesh network and is intended for Dali luminaires without sensors.

Highbay sensors

sensotec-hb-pir-3360.svg
HB PIR 3360 NET sensor

A reliable motion detector with a long range, ideal for high ceilings in industrial buildings or commercial properties. For installation heights of up to 14m and a maximum detection area with a diameter of 36m, this high-precision PIR sensor enables the monitoring of up to 1000 square metres.

sensotec-hb-pir-345.svg
HB PIR 345 NET sensor

The highbay motion detector reliably monitors a rectangular detection area up to 30x4m and a mounting height of 14m. Ideal for detection from great heights in warehouses, high-bay warehouses, machine shops, check-in and waiting halls.

sensotec-hb-pir-345-3360-anschlussvarianten.svg
Connection variants

Both highbay sensors are available in the versions (from left):
✓ Wire with wires for wiring to the luminaire
✓ Zhaga base
✓ Intra for luminaire installation

360° view using the example of the HB PIR 345:
Wire | Zhaga | Intra

Ecosystems

Thanks to its compatibility with various ecosystems such as Silvair, Casambi and Ingy, you get maximum flexibility and a wide range of options when integrating sensor solutions. The SENSOTEC sensor takes control of the directly connected DALI luminaires, enabling efficient and intelligent lighting control.

Reliable control of the sensors is possible both remotely and locally via radio connection. Silvair and Casambi use Bluetooth, while Ingy relies on Wirepas.

✓ Sensors can be configured and managed intuitively using a desktop application or mobile devices such as tablets and smartphones.


sensotec-net-sensoren-ecosystem-casambi.svg
Casambi
sensotec-net-sensoren-ecosystem-oem.svg
Your own solution

Do you have a solution for radio-based lighting control in use? If required, the specifications of the SENSOTEC sensors can be adapted to your customer requirements in a development project.
